TM10-3950-672-24-2
System
Maximum Allowable Intake
Restriction at Rated Speed and
Load with Dirty Air Filter Element
mm H20 [in. H20]...............
508
[20]
Restriction at Rated
Speed and Load
mm Hg [in. Hg] .................
------------------------------------------ 76.2 [3] -----------------------------------------------------
Maximum Allowable Restriction
to Pump With Dirty Filter
mm Hg [in. Hg] .................
----------------------------------------- 95 [3.75] ----------------------------------------------------
Maximum Allowable Return
Line Restriction ...................
-----------------------------------------518 [20.4) ---------------------------------------------------
mm Hg [in. Hg]
Electrical System
Minimum Recommended Battery
Capacity With Light
Accessories* ......................
625CCA
-12 V Starter
With Heavy Accessories*.
-12 V Starter .......................
800CCA
----------------------------------------------- ----------------------------------------------------------
of Starting Circuit With
- 12 V Starter Ohms ...........
-------------------------------------------- 0012 ------------------------------------------------------
*Typical light accessories include (alternator, small steering pump, and disengaged clutch)
**Typical heavy accessories include (hydraulic pump and torque converter)
5-7
