Oil Pan
A front sump, rear sump or center sump pan options
may be used depending on the application.
The
mounting of the oil pick up tube will vary with the pan
used.
Rear Crankshaft Seal
The rear crankshaft seal is mounted in a housing that
bolts to the rear of the block. Double lipped Teflon seals
are used. The sealing surface on the crankshaft must
be clean and free of oil during installation of the seal.
Diagnosing Base Engine Component Malfunctions
Valve Train and Head Assembly
The sound emitted from the overhead can indicate a
valve train problem. Loose rocker levers will clatter. A
squeaking noise can mean lack of lubrication for
adjusting screw and the push rod socket.
Caution: If the one of the individual
support pedestals is removed during
inspection or repair, all head bolts
must be retightened according to the
