TM 10-3950-672-24-2
Engine Installation
Caution: Do not exceed the torque value for the
engine supports.
Check the data plate to verify that the replacement
engine is the same model and rating as the engine that
was removed.
Note: Install all accessories and brackets that had been
removed from the previous engine.
Torque Value: 77 N
[57 ft-lbs]
n
Use the lifting eyes to lift the engine. Keep tension on
the hoist while you align the engine in the chassis and
tighten the engine mounts.
Connect the engine and chassis parts in the reverse
order of removal.
When connecting the cable/rod to the control lever,
adjust the length so the lever has stop-to-stop
movement.
5-310
