TM 5-3810-300-24 & P2
TABLE 4-2 . SINGLE - REDUCTION DRIVE UNIT TORQUE LIMITS
TORQUE LB.FT.
NOMENCLATURE
BOLT SIZE
Pinion Bearing Cage
3/8"-16
30-40
To Carrier Capscrews
7/16"-14
50-65
1/2"-13
80-105
5/8"-11
130-170
Oil Filler Plug
Thread into Carrier
Housing to Allow
One Thread Stand
Out
Adjusting Ring Lock
(Some Models Only)
Adjusting Ring Lock to Diff.
5/16"-18
15-20
Bearing Cap Capscrews
5/16"-18
22-28
Diff. Case Capscrews or Bolts
3/8"-16
35-50
and Nuts (Long & Short)
7/16"-14
60-75
1/2"-13
90-120
1/2"-20
105-135
5/8"-11
185-235
5/8"-18
210-270
3/8"-16
35-50
7/16"-14
60-75
1/2"-13
90-120
1/2"-20
105-135
5/8"-11
185-235
5/8"-18
210-270
Gear to Diff. Case Bolts
5/8"-18
210-270
Nuts
1/2"-20 L
105-135
5/8"-11
150-190
1/2"-13
90-120
Diff. Case Bolt With Nut
"Thru Bolt" Type (Some Models
Only)'
Diff. Bearing Cap to Carrier
9/16"-12
116-129
Capscrews
5/8"-11
160-180
3/4"-10
290-320
7/8"-14
375-415
7/8"-9
1470-520
4-275
