TM 5-3810-300-24&P-3
7.3.1 SOLENOID SWITCH
2. Remove wires from switch terminals (377) and
1. Attach the switch to the mounting plate with four
(378). Tag wires for identification.
bolts, plain washers, lock washers and nuts.
3. Remove four nuts, lock washers, plain washers,
and bolts, and remove solenoid switch.
2. Connect the battery cable and the starter switch
wire to the terminal (376) and connect the starting motor
cable to the terminal (379).
Install Solenoid Switch
3. Connect the wires to the switch terminals (377) and
The switch may be reinstalled on the engine as outlined
(378).
below:
Page 345
