TM 5-3810-300-24 & P3
71 VEH.
ENGINES
1.3000C
CRANKSHAFT PULLEY
........................................... TYPES..........................................
3
3
3
PART
333333
.....FIG .........NUMBER ............ NAME AND DESCRIPTION..............
033384
1
4
7
1.3280 - PULLEY, CRANKSHAFT
A PULLEY ASSY INCLUDES ITEMS
IN 1.3311.
NPN
PULLEY (CUSTOMER...... FURNISHED).
5141158
PULLEY, 7 1/2' DIA., 3 GROOVES..........
5145390
PULLEY, 9' DIA., 2 GROOVE; 3/8'W.......
5139346
PULLEY ASM., 7 1/2' DIA., 3 GROOVES
1
5162919
PULLEY, 7 1/2' DIA., 4 GROOVES..........
5147168
PULLEY ASM., 7 1/2' DIA.,......................
GROOVES)
5139735
PLATE, LOCKING (7.1505) .....................
4D
117982
KEY, 3/8'X1 1/4' WOODRUFF (12.9350).
2
180120
BOLT, 3/8'-16X3/4' (12.9001) ..................
186627
BOLT, 3/8'-24X 1' (12.9001) ....................
180121
BOLT, 3/8'-16 X7/8' (12.9001) .................
103321
LOCKWASHER, 3/8' (12.9200) ...............
1.3290 - RETAINER, CRANKSHAFT PULLEY
4A
5157930
RETAINER (2 3/8' O.D.) ..........................
1
4A,D
5153623
BOLT, 1'-14X2 1/4' L. (12.9001) ..............
4A,D
5160266
BOLT, 1'-14X2 3/4' L................................
1
1.3310 - HUB, CRANKSHAFT PULLEY
5178036
HUB .........................................................
1.3311 - INSULATOR ASSY., CRANKSHAFT PULLEY
HUB
5145047
INSULATOR ASSY ..................................
1
147489
BALL, 3/8' DIA., STEEL (12.9670) ...........
3
55
