TM 5-3810-300-24 & P3
7 1 VEH
ENGINES
34000BLOWER
........................................... TYPES..........................................
PART
5
1
1~
1
1
1
FIG
NUMBER
NAME AND DESCRIPTION ....................
1
1
1
41
6
1
1
6
8
1
5
8
2
24
2
6
9
7
4
8
8
8
4
8
0
7
3.4129 -
HUB KIT, BLOWER ROTOR GEAR
A KIT INCLUDES ITEMS IN 3.4130,........
3.4135 AND 3.4137.
3A,B
5192751
HUB KIT...................................................
1
3.4130 - HUB, BLOWER ROTOR GEAR
3A,B
5173366
HUB .........................................................
1
3A
103340
WASHER, 5/16' FLAT (12.9190) .............
6
3A
103320
LOCKWASHER, 5/16' (12.9200) .............
6
3.4135 - PLATE, BLOWER ROTOR GEAR HUB
3A
5173365
PLATE......................................................
2
3A
5173362
BOLT (PLATE TO HUB) ..........................
3
3A
5173363
BOLT (PLATE TO GEAR)........................
3
3A
5117729
* BOLT(PLATE TO GEAR).......................
* OBSOLETE.
3.4137
SPACER. BLOWER ROTOR GEAR HUB
3A
5173364
SPACER ..................................................
3
3A
5142305
SPACER ..................................................
3.4140 - PLATE, BLOWER HOUSING END
3A
5193719
PLATE ASSY. (INCLUDES DOWEL PINS)
2
3B
5142234 * PLATE ASSY. (INCLUDES DOWEL PINS)
3B
5114528
PIN (DOWEL) ..........................................
4
3B
5142309 - PLATE ASSY. (INCLUDES DOWEL PINS)
3B
5142304
PIN (DOWEL) ..........................................
3A,B
1117296
SCREW, 5/16'-18X1 1/2' FL. H D ............
4
(12.9010)
* OBSOLETE.
3.4158
CARRIER, BLOWER HOUSING END PLATE
SEAL RING
5110329
CARRIER.................................................
3.4159 -
COLLAR, BLOWER HOUSING END PLATE
SEAL RING
5110330
COLLAR...................................................
168
