TM10-3950-672-24-2
Assemble the removed parts in the reverse order of
removal.
m
m
(Thermostat Mounting) 24 N ([18 ft-lb]
m
Cup Plugs Replacement
Remove the cup plugs from the coolant passages as
shown.
Apply a bead of Loctite 277 to the coolant passage cup
plugs.
Drive the plugs in until the outer edge is flush with the
counter sink in the block.
5-65
