TM10-3950-672-24-2
Water Pump - Replacement
Preparatory Steps:
Drain the coolant.
Remove the drive belt.
1
3mm
Remove the two capscrews and water pump, and
complete the following steps.
Clean the sealing surface on the cylinder block.
Inspect impeller blades for wear or corrosion.
Inspect pump for free rotation. Check weep hole for
evidence that seal has been leaking.
Install the new o-ring into the pump groove.
5-61
