TM 5-3810-300-24 & P3
71 VEH. ENGINES
4.2000A
OIL FILTER
......................................... COLUMN........................................
PART
4
5
6
1
2
2
FIG
NUMBER
NAME AND DESCRIPTION.....................
6
1
0
9
7
9
4
5
8
0
6
6
8
3
7
4
3
6
0
4.2240 - FILTER, OIL -
REFER TO ASSEMBLY BREAKDOWN PAGE AS
IF OIL COOLER ADAPTORS OTHER THAN
5123635 OR 5123636 IN 4.2290 ARE
REQUIRED, ORDER FILTER REPLACEMENT
BY COMPONENTS; DO NOT ORDER FILTER
ASSY FILTER ASSYS DO NOT INCLUDE
DECALS IN 4.2240.
5194287 FILTER ASSY (FULL FLOW) (A OR B ........................
ENGINES) (PAGE Al)
5194288 FILTER ASSY (FULL FLOW) (C OR D .......................
ENGINES) (PAGE Al)
5572942#& FILTER ASSY ....(BY-PASS) (PAGE Al) --
1
5181797 @ FILTER ASSY (FULL FLOW) (5147683) ...................
2325391 FILTER ASSY (BY-PASS) (LUBER-FINER)................
(PAGE Al)
3L 5137659 @ FILTER ASSY (FULL FLOW) (5147683) ...................
5573199 DECAL (BY-PASS FILTER) ........................................
5573162 DECAL (FULL FLOW FILTER) ....................................
AR
5146010 PLUG, 1/4' PIPE (12.9550)..........................................
AR
5133279 BUSHING, 1/2'X1/4' (.062'...........................................
RESTRICTION) (4.3001)
180121
BOLT, 3/8'-16X7/8' (12.9001) ......................................
186ee679 BOLT, 3/8'-16X1 1/4' (12.9001) ...................................
103321
LOCKWASHER, 3/8' (12.9200) ...................................
# INCLUDES ITEMS IN 4.2440.
& NOT SERVICED, REPLACED BY
1-5570141 FILTER, 2-5573419
@ NOT SERVICED, COMPONENTS ARE
AVAILABLE FOR A COMPLETE
REPLACEMENT USE ASSY NUMBER SHOWN
IN PARENTHESES PLUS 5111798 AND
12800.3 @ TWO EACH.
4.2250 - ELEMENT, OIL FILTER
3L 5573014+ ELEMENT (PAPER) (DOMESTIC USE).......................
1
(FULL-FLOW) (AC TYPE PF-132)
+ INCLUDES GASKET IN 4.2300.
4.2270 - SPACER, OIL FILTER
5570487= SPACER .....................................................
= NO LONGER AVAILABLE FOR SERVICE.
194
