TM 5-3810-300-24 & P3
71 VEH. ENGINES
4.2000A
OIL FILTER
......................................... COLUMN........................................
PART
A
C
E
G
I
K
M
FIG
NUMBER
NAME AND DESCRIPTION.....................
B
D
F
H
J
L
N
5194287 FILTER ASSY (A OR B ENGINES) .............................
1
5194288 FILTER ASSY (C OR D ENGINES).............................
1
5572942 @ FILTER ASSY .........................................................
1
5181797 = FILTER ASSY .............................................................
1
2325391 FILTER ASSY..............................................................
1
3L 5137659 = FILTER ASSY .............................................................
1
@ NOT SERVICED, USE 1-5570141
FILTER, 2-5127156 BRACKETS,
= SHOWN FOR COMPONENT REFERENCE
2-5571568 BOLTS.
ONLY.
4.2250 * ELEMENT, OIL FILTER
INCLUDES GASKET IN 4.2300.
3L 5573014 ELEMENT (AC TYPE PF- 132) (PAPER)....................
1
1
1
1
5187830 ELEMENT (METAL) (EXPORT USE) ..........................
1
1
3B 6572425 ELEMENT (AC TYPE P-1 17)......................................
1
1
5573898 ELEMENT (AC TYPE C-267) ......................................
5570487 * SPACER
1 ...............................................................
1
4.2270 - SPACER
OIL FILTER
* NO LONGER AVAILABLE FOR SERVICE.
3B 6674008 SHELL ASSY(INCLUDES PLUG)................................
1
1
1
4.2280 - SHELL, OIL FILTER
39 657409 08 SHELL ASSY (INCLUDES PLUG)...............................
1
5570480 PLUG, DRAIN (2.3050) ...............................................
1
1
1
1
112578
PLUG, 1/4' PIPE (12.9550)..........................................
1
1
1
1
* OBSOLETE
4.2290 - COVER, OIL FILTER
A COVER INCLUDES PLUGS.
3B 5571505 COVER (SINGLE BY-PASS FILTER)..........................
1
5574128 * COVER ASSY(INCLUDES ITEMS IN ..........................
1
4.2310,4.2320, 4.2330)
3L 6123635 ADAPTOR (A OR B ENGINE) (4.4110).......................
1
3L 5123638 ADAPTOR (C OR D ENGINE) (4.4110) ......................
1
5188923# ADAPTOR (5147684) ...................................................
1
5137651 # ADAPTOR (5147684) ..................................................
1
198
