TM 10-3950-672-24-2
Low Pressure Lines and Fuel Filter - Venting 10mm
Open the bleed screw.
Operate the hand lever until the fuel flowing from the
fitting is free of air.
Tighten the bleed screw.
m
[6 ft-lb]
Injection Pumps - Venting 8mm
Air/Fuel can be pumped from this location on the Lucas
CAV pump with the hand lever on the lift pump, if the
Warning: It is necessary to put the engine in the
"run" position: Because the engine may start, be
sure to follow all the safety precautions. Use the
normal engine starting procedure.
Caution: When using the starting motor to vent the
system, do not engage it for more than 30 seconds
at a time:
Wait two (2) minutes between
engagements.
Air can also be vented through the fuel drain manifold
line by operating the starting motor.
5-84
