TM 10-3950-672-24-2
High Pressure Lines - Venting 17mm
Warning: The pressure of the fuel in the line is
sufficient to penetrate the skin and cause serious
bodily harm.
Loosen the fittings at the injector, and crank the engine
to allow entrapped air to bleed from the line. Tighten
the fittings.
Warning: Do not bleed a hot engine as this could
cause fuel to spill onto a hot exhaust manifold
creating a danger of fire.
Start the engine and vent one line at a time until the
engine runs smoothly.
Fuel Filter - Replacement
80 to 95mm, Filter Wrench
Remove the combination water separator/fuel filter.
80 to 95mm, Filter Wrench
If used, remove the two filters from the dual filter
adaptor.
5-85
