TM 10-3950-672-24-2
Note: Mark the cylinder block so you can align the oil
hole in the cylinder block with the oil hole in the bushing.
Install the bushing so that it is even with the front face of
the cylinder block.
Caution: the oil hole must be aligned.
Measure the installed bushing.
Limits
Inside Diameter: 54.146mm [2.1315 inches]
5-202
