TM10-3950-672-24-2
Injection Pump - Service Tools
The following special tools are recommended for repairing the fuel injection pump. Use of the tool is shown on the
appropriate procedure.
Tool No.
Tool Description
Tool Illustration
Protective Sleeve
3376930
Used to replace the o-ring on the shut down solenoid for
the Lucas CAV fuel pump.
Protective Sleeve
3376931
Used to replace the o-ring on the pressure end cap of the
timing advance mechanism on the Lucas CAV pump.
Injection Pump Repairs Lucas CAV
DPA
Locking Screw/O-Ring Replacement
Precisely mark the shaft position before removing the
locking screw.
5-264
