TM 10-3950-672-24-2
15 mm
Remove the locking screw and washer.
Install a new o-ring. Replace special washer, if required.
15 mm
Verify the shaft is still aligned and install the locking
screw assembly.
Torque Value: 30
Nom [22 ft4b]
Back Leakage Valve Replacement/ Inspection
16 mm
Remove the back leakage valve and sealing washer.
5-265
