TM 10-3950-672-24-2
Universal Bushing Installation Tool
Install the camshaft bushing flush with the block.
Be sure the oil hole is aligned.
A 3.2mm [0.128 in] diameter rod must be able to pass
through the hole.
Measure the installed camshaft bushing.
Camshaft Bushing Bore
mm
in
54.107
MIN
2.1302
54.146
MAX
2.1317
Dipstick Tube - Replacement
Pliers
If the dipstick tube is loose or damaged, remove it from
the cylinder block.
5-292
