TM 10-3950-672-24-2
Gear Housing and Timing Pin Assembly - Inspection
Visually inspect the gear housing for cracks or damaged
sealing surfaces.
Inspect the timing pin housing and pin for damage.
Gear Housing - Disassembly
Do not remove the timing pin housing unless it is
damaged or leaking, or the gear housing is being
replaced.
procedures.
Fuel Pump Stud - Replacement
13 mm
To install or remove fuel pump studs, use two nuts jam
locked onto the stud.
5-304
