TM 10-3950-672-24-2
Install a new gasket and, if required, new timing pin
assembly. Hold the pin (A) in the hole (B) in the
camshaft gear to align the housing.
m
Gear Housing or Gasket - Replacement
Preparatory Step:
Remove the camshaft.
Remove the gear driven accessory drive if the
engine is so equipped.
10 mm
Remove the gear housing and gasket.
Clean the gasket material from the cylinder block.
5-210
