TM 5-3810-300-24 & P2
TABLE 4-1.
SINGLE REDUCTION HYPOID - DRIVE UNIT TORQUE LIMITS (continued)
NOMENCLATURE
BOLT SIZE
TORQUE LIMITS LB.FT.
Carrier to Housing Stud
1/2"-20
80-105
Nuts
5/8"-18
160-205
3/4"-16
290-370
Inspection Hole Plug
Thread into Carrier
and Allow One Thread
Standout
Adjusting Ring Lock
(Specified Models Only)
Adjusting Ring Lock to
5/16"-18
15-20
Diff. Bearing Cap Capscrews
5/16"-18
22-28
NOTES
FOR ALL FASTENERS
ALL TORQUES GIVEN APPLY TO PARTS COATED WITH MACHINE OIL.
FOR DRY PARTS INCREASE TORQUES 10%.
FOR PARTS COATED WITH MULTI-PURPOSE.
GEAR OIL DECREASE TORQUE 10%.
NUTS ON STUDS TO USE THE SAME TORQUE AS FOR DRIVING THE STUD.
INDICATES TORQUE VALUES
FOR FASTENERS USING LOCKWIRE
OR COTTER PINS.
ALL OTHER TORQUE VALUES ARE
FOR FASTEN4ERS NOT USING LOCKWIRE
OR COTTER PINS.
4-250
