TM 5-3810-307-24-2-2
Inspection
Visually inspect the turbocharger compressor V-band
outlet and the air transfer pipe connection for dents or
fretting.
Replace the turbocharger compressor housing or air
transfer pipe, if damaged.
Air Crossover Tube - Cleaning and
Inspection for Reuse (10-05)
Cleaning
WARNING
When using a steam cleaner, wear protective
clothing and safety glasses or a face shield.
Hot steam will cause serious personal injury.
Use solvent or steam to clean the air crossover tube.
Dry with compressed air.
Inspection
Visually inspect the air crossover tube for cracks or
damage.
Visually inspect the hose sealing surfaces for pitting or
damage. Replace damaged parts.
Charge Air Cooler (CAC) - Cleaning
and Inspection for Reuse (10-06)
Cleaning
NOTE
If the engine experiences a turbocharger
failure or any other occasion where oil or
debris is put into the CAC, the CAC must be
cleaned.
Remove the CAC from the vehicle. Refer to the vehicle
manufacturer for instructions.
