TM 10-3950-672-24-2
14mm, 16mm, 19mm and 24mm
Remove the supply line assembly from the two Lucas
CAV pump fittings.
Note: Replace the seals in the fittings if the line is
disassembled.
17mm
Install the supply line in the reverse order of removal.
Tighten line securely to pump fittings.
32 N [27 ft-lbs]
m
Operate the hand lever 10-20 strokes to fill the supply
line.
5-94
