TM 10-3950-672-24-2
Inspect the valve to be sure it is not stuck.
Inspect the sealing surfaces for possible leak paths.
16mm
Assemble the back leakage valve and new washers.
Tighten the valve to 30 N [23 ft-lbs].
m
17mm
Connect the high pressure line.
5-100
