TM10-3950-672-24-2
10mm
Install the front cover and gasket.
Note
Install the capscrews but do not tighten at this time.
Use the alignment/installation tool from the seal kit to
align the cover to the crankshaft.
10mm
Torque Value: 24 N
[18 ft-lbs]
m
Remove the alignment/installation tool.
Caution
Always use a seal pilot when you install a seal.
Apply a bead of Loctite 277 to the outside diameter of
the seal. Install the pilot from the seal kit onto the
crankshaft. Install the seal onto the pilot and start into
the front cover. Remove the pilot.
5-139
