TM10-3950-672-24-2
Measure the tip clearance.
Limit
Maximum Clearance: 0.1778mm [0.007 inch]
Measure the clearance of the gerotor drive/gerotor
planetary to port plate.
Limit
Maximum Clearance: 0.127mm [0.005 inch]
Measure the clearance of the gerotor planetary to the
body bore.
Limit
Maximum Clearance: 0.381mm [0.015 inch]
Measure the gears backlash.
Limits (Used Pump)
0.05 to 0.38mm
[0.003 to 0.15 inch]
5-136
