TM 10-3950-672-24-2
Brass Drift Pin
Warning: Wear eye protection when you drive the
gear from the flywheel. Do not use a steel drift pin.
Use the drift pin to drive The ring gear from the
flywheel.
Heat the new ring gear for 20 minutes in an oven
preheated to 127C [260F].
Warning: Wear protective gloves when you install
the heated gear.
Install the gear. The gear must be installed so the bevel
on the teeth is toward the crankshaft side of the
flywheel.
Rear Seal - Replacement
1/8 inch Drill
Drill two holes 180 degrees apart into the seal carrier.
5-216
