TM 10-3950-672-24-2
24 mm
Remove the pressure end plug and o-ring.
13 mm
Remove the cap nut and sealing washer.
19 mm
Remove the head/locating fitting assembly.
Do not lose the check ball.
Remove the housing and slide the advance piston from
the bore.
5-273
