TM10-3950-672-24-2
Fuel Shutoff Valve - Check
Note
Check all connections for loose or corroded
connections and for broken wires.
Remove the valve. Ground the valve and connect 12
volts DC to the terminal and observe plunger
movement.
Oil Pressure Switch and Temperature Sensor
When diagnosing problems with either the pressure
switch or the temperature sensor, check for loose or
corroded connections and for broken wires.
5-153
